Film Face Shuttering Plywood

When it comes to stiffness, stress/weight ratio and bonding durability, Shuttering Plywood has no equal. Ideally suited for concrete framework for beams pillars, columns, flooring & slab framework, symmetrical and non-symmetrical framework. Shuttering Plywood comprises uniquely processed wood plates that are perfectly suited to centering and shuttering. If employed correctly, it can greatly reduce construction costs.

 Available Options
  • Film Face
  • Resin Coated
  • Plain

Technical Specifications



Bending Radii (cm)
Phenol Bonded & BWP Grain
Thickness 9 mm 12 mm
Parallel to Face Grain 215 330
Perpendicular to Face Grain 165 255
Loading and Deflection

Taking the maximum permitted deflection at 1:1270 (i.e. 1/270 of the span between the bearers), the maximum load permitted is given below.

30 cm 40 cm 50 cm 60 cm
Parallel to face grain 9 mm
12 mm		 760
1220		 320
540		 195
390		 110
170
Perpendicular to face grain 9 mm
12 mm		 1270
1950		 540
850		 320
640		 170
360
*** If wet boards are used, the load shown above should be reduced to 75%



Standard Sizes

8×4 (mm)

Density

0.60 gm/cc : 1.00 gm/cc (as per requirement)

Weight of 8×4 sheet of
12 mm 23 kg, 30kg, 34 kg, 38 kg
18 mm 36 kg, 45 kg, 52 kg, 60 kg
